Details display
1.Front support and guide rail
Standard upper and lower mould design, specially designed for metal plates;
Simple design structure, powerful function, can be adjusted up and down or left and right movement
2.Rear stop design
The back stop assembly of the machine adopts high-precision ball screws and adjustable stop fingers to ensure the precise positioning of various punches.Compared with manual adjustment, it is more flexible and adaptable.
3.0Main motor;
Adopting the world famous motor brand, the after-sales service is more guaranteed;
Adopt electro-hydraulic drive system mixed drive, to achieve the fastest cycle speed, effective energy saving of 60%.
high working efficiency, low noise, and more convenient maintenance.
4.Control system; Basic controller
1.high-definition liquid crystal display, Chinese and English can be selected;
Built-in residence time, unloading delay design function, easier to operate;
One-key parameter backup and recovery function;
Technical Parameters
| ITEM | VALUE |
| Model | 130T3200 |
| Axes | Y1, Y2, X, R and V(Crowning) |
| Slider Stroke (mm) | 200mm |
| Max Opening Height(mm) | 480mm |
| Throat Depth (mm) | 400mm |
| Length of Working Table (mm) | 3200 mm |
| Width of Working Table (mm) | 150mm |
| Dimension | 3850x1850x2600mm |
| Weight (KG) | 9000 |
| Motor Power (kw) | 11kw |
| Warranty | 2 years |
|
Material / Metal Processed |
Brass / Copper, Stainless Steel, ALLOY, Carbon Steel, Aluminum, Mild Steel |
