Details display
1.High-precision bed
Cutting machine body structure is solid, welded base, through the large-scale gantry milling machine processing and become.
The surface of the bed has been processed through many processes, and it will not be deformed after a long time of use.
2.laser head
Adopting world famous brand, compact design, modular, easy maintenance;
Durable; multiple protection lenses, 2-channel optical water cooling, effectively extend the continuous working time;
Closed-loop stepping auto-focus, focusing speed 100mm/s, repeatability 1μm.
3.water cooler
According to different working environments, the temperature is automatically adjusted without changing the setting parameters;
Reduce the temperature of laser source and laser head through water circulation, thus protecting the main components;
4.Servo motor
Adopting high-strength servo motor to improve cutting precision and speed, perfect cutting edge, smooth plane, perfect cut;
5.Control system
Adopting professional cutting control system for better cutting of metal sheets;
Convenient after-sale software, applicable to various metal cutting methods.
6.Pipe Type
Square tub / Round tube / Rectangular tube
H C L I Beam
One machine in hand, worry-free pipe cutting
Data parameters
| 1 | Machine Name | Fiber Laser cutting machine |
| 2 | Model | LF-T3015 |
| 3 | Laser machine cutting area | 3000x1500mm
tube diameter 20mm-200mm(350mm max) |
| 4 | Fiber Laser Power | 1500/2000/3000w(optional) |
| 5 | Laser wave length | 1064nm |
| 6 | Transmission system | Gear + rails (we have standard brand,we can also produce as your requirements) |
| 7 | X.Y axis location accuracy | ±0.01mm |
| 8 | X.Y axis repeat location accuracy | ±0.01mm |
| 9 | X.Y axis max moving speed | 60m/min |
| 10 | Max cutting speed | 1–60m/min
(it will according to metal material and laser power and machine configuration) |
| 11 | Cutting thickness | Detailed in the following cutting thickness |
| 12 | Application Material | Metal sheet Iron/CS/SS/Aluminum/Copper and all kinds metal |
Sample display
